30" Free-Standing Gas Range - JGB620DEFBB
This product is discontinued and has been replaced by the model below.
30" Free-Standing Gas Range
Model: JGB620DEFBB
This product is discontinued and has been replaced by the model below.
30" Free-Standing Gas Range
Model: JGB620DEFBB
Color : Black on Black
Replaced By
Key Features
12,500 BTU burner
Precise Simmer burner
Self-clean oven
5.0 cu. ft. oven capacity
Sealed cooktop burners
Electronic oven controls
California Prop 65
Available from Devixel Super King Appliance, serving customers throughout Missouri.
Features
Specifications
Certifications
Features
12,500 BTU burner
Precise Simmer burner
Self-clean oven
5.0 cu. ft. oven capacity
Sealed cooktop burners
Electronic oven controls
California Prop 65
Certifications
California Prop 65
Specifications
FEATURES
| Drawer Type | Storage |
| Burner - Left Rear | 9,500 BTU |
| Oven Rack Features | 2 Oven Racks |
| Cooktop Surface | Black |
| Cooktop Surface | One-Piece Upswept |
| Cooktop Surface | Porcelain-Enamel |
| Control Type | Electronic Touch |
| Oven Control Features | Audible Preheat Signal |
| Oven Control Features | Auto Self Clean |
| Oven Control Features | Certified Sabbath Mode |
| Oven Control Features | Oven Control Lock Capability |
| Ignition System | Electronic |
| Cooktop Type | Standard Grates |
| One-Piece Drip Pans | Optional Accessory |
| Burner - Right Front | 12,500 BTU |
| Burner - Left Front | 9,500 BTU |
| Cooktop Burner Grate Material | Heavy Steel |
| Oven Cleaning Type | Self-Clean |
| Burner - Right Rear | 5,000 BTU Precise Simmer |
| Product Type | Free-Standing Single Oven |
| Interior Oven Light | 1 Incandescent |
| Configuration | Range with Storage Drawer |
| Cooking Technology | Traditional |
| Fuel Type | Natural Gas (factory set) |
| Cooktop Burner Type | Sealed |
POWER / RATINGS
| Top Burner BTU Rating - Nat. Gas (000's BTU's) | (1) 12.5; (2) 9.5, (1) 5.0 |
| Bake/Broiler BTU Rating - Nat. Gas (000's BTU's) | 16.0 Bake / 13.5 Broiler |
| Bake/Broiler BTU Rating - LP (000's BTU's) | 16.0 Bake / 12.0 Broiler |
| Top Burner BTU Rating - LP (000's BTU's) | (2) 9.5; (1) 11.0; (1) 5.0 |
| Volts/Hertz/Amps | 120v; 60Hz; 15A |
WARRANTY
| Labor Warranty | Limited 1-year entire appliance |
| Parts Warranty | Limited 1-year entire appliance |
| Warranty Notes | See written warranty for full details |
APPEARANCE
| Color Appearance | Black on Black |
| Oven Door Features | Big View Oven Window |
| Cooktop Burner Grate Color | Matte Black |
| Handle | Color-Matched |
| Handle | Designer Style |
| Control Knobs | Color-Matched |
ACCESSORIES
| LP Conversion Kit | Included |
CAPACITY
| Total Capacity (cubic feet) | 5 |
Warranty
| Parts | 1 Year |
| Labor | 1 Year |
Number of Boxes, Shipping Dimensions, & Shipping Weight
| Number of Boxes | 1 |
| Shipping Width | 35 in. |
| Shipping Height | 51.25 in. |
| Shipping Length | 33.75 in. |
| Shipping Weight | 245 lbs. |
| Total of Shipping Weight | 245 lbs. |
| Source | Calculation |
Cubic Feet Measurement & Dimensional Weight
| Cubic Feet Measurement | 23.08 ft³ |
| Dimensional Weight | 286.98 lbs. |
| Total of Cubes | 23.08 ft³ |
| Total of Dimensional Weight | 286.98 lbs. |
Dimensions & Weight
| Width | 30 in. |
| Height | 46.25 in. |
| Length | 28.75 in. |
| Weight | 205 lbs. |
| Depth with Door Open | 46.25 |
| Oven Interior Dimensions (W x H x D) (in.) | 24 x 19 x 19 |
| Depth Without Handle | 26.25 |
| Net Weight | 205 |
| Approximate Shipping Weight | 225 |
| Height to Cooking Surface (in.) | 36 - 36 1/4 |
| Cabinet Width | 30 |
